Farnese Technicut Mono Block Saw, 5 Axis 20hp

The Technicut Mono is a 5 axis, CNC controlled saw that combines the features of the standard Technicut with a rigid and convenient mono block frame. The machine’s support rails and tilting worktable are constructed of high quality steel with a durable galvanized finish. A powerful 20hp, direct drive motor cuts materials smoothly and easily.  The cutting head has the ability to tilt 90 degrees and rotate 360 degrees.  Vacuum manipulators are placed on both sides of the cutting head for quickly moving materials as needed. A center water fed ½” gas spindle allows the operation of a drill or a milling tool in addition to the blade. This gives users the option to program the unit to drill out the corners of internal cutouts. The Technicut’s software is simple and easy to use; operators may also use the machine in fully automatic, semi-automatic, or manual mode. The CAD/CAM system supplied with the machine allows any 2D shapes to be produced, the program can include vacuum movements of the material to produce complicated cuts.  The Technicut also features the ability to connect to the internet so the unit may be remotely accessed for troubleshooting or training purposes.

• Full 5 axis CNC control for accurate and efficient production
• Powerful 20hp direct drive motor cuts through materials smoothly and easily
• Cutting head tilts 90 degrees and rotates 360 degrees
• Water fed ½” gas spindle allows drilling and milling operations
• High quality steel rails and table with a long lasting galvanized finish
• Monoblock construction is rigid and easy to install
• Vacuum material manipulators quickly move materials, providing added efficiency and versatility
• Simple and easy to use software
• Tilting worktable makes loading and unloading safer and easier
• Laser Cutting Guide provides a visual guide when making manual cuts
• Blade Thickness Probe monitors blade diameter to adjust blade parameters
