Alpha® has re-designed and improved the already popular Alpha® Guide Rail and Carriage System in several sizes which now accommodates our 6” PSC-150 Stone Cutter. The new Carriage Assembly (ASC-6CSM) is designed for straight cuts as well as miter cuts. This carriage has three templates included that assist in the installation of the stone cutter for left-side or right-side miter cutting and straight cutting. If you have two sets (Stone Cutter & Carriage Assembly) set up in each direction on the same guide rail, you can cut a V and the edges would be ready for lamination. If you have a single setup (Stone Cutter & Carriage Assembly), the guide rail needs only be set up once on the material. The Stone Cutter can then be positioned to create a miter cut, then repositioned for a second miter cut to create the V.
- One System for Straight, Curve and Miter Cuts
- Precise Miter Cuts for Laminated Waterfall Edge and Book Matching
- Miter Cut 3/4” (2cm) Material with Ease
- One-Time Easy Setup on the Guide Rail Allows for Two Different Miter Cut Positions for Lamination Prep
- Save Time and Increase Shop Productivity
- Kit Contains: 2-ESC-150 Stone Cutters, 2-6″ Eclipse II Blades, 2-6” Carriage Assemblies, Guide Rail Set (4′, 7′, 12′ / 1.2m, 2.1m, 3.6m) & Surface Protection Tape
- One system for straight, curved, and miter cuts
- Precise miter cuts for laminated waterfall edge and book matching
- Miter cut 3/4” (2cm) material with ease
- One-time easy setup on the guide rail allows for two different miter cut positions for lamination prep
- Save time and increase shop productivity
Product Attributes
| Air Consumption | 32 CFM |
| Electric Pneumatic | Pneumatic |
| Equipment Included | (2) PSC-150 Stone Cutters; (2) 6” Carriage Assemblies; (1) Guide Rail Set (4′, 7′, 12′ / 1.2m, 2.1m, 3.6m); (1) Surface Protection Tape; |
| Motor | 2.0 hp |
| Air Inlet | 3/8″ NPSM |
| Air Pressure | 90 PSI |
| Max Blade Diameter | 6″ |
| Arbor Bore | 7/8″ |
| RPM | 8,500 |
| Waterfed | Yes |
| Water Inlet | 1/4″ BSPP |
